Programmable Switching Power Supplies, UTP1306 1-Channel
UTP1000 Series, Programmable Switching Power Supplies:
- The UTP1300 series power supply is a cost-effective switch-type DC regulated power supply with a single output.
- It provides a pure output, outstanding performance indications, and can suit a wide range of testing requirements.
- Used for product debugging and maintenance, quality control and testing, automated production testing, training trials, and so on.
- A single output.
- Output: 32V, 6A/10A.
- Resolution is 10 mV/1 mA.
- Protection against overvoltage or current.
- Three categories of one-key recall of stored data.
- The overcurrent/voltage protection value can be set.
- Independent output switch.
Specifications:
- UTP1000 Series, Programmable Switching Power Supplies.
- Output voltage 0-32V.
- Output current 0-6A.
- Output power 192W.
- Load regulation CV ≤0.1%+5mV.
- Load regulation CC ≤0.2%+3mA.
- Power regulation CV ≤0.01%+5mV.
- Power regulation CC ≤0.2%+3mA.
- Power Input voltage: 110V AC/220V AC, 50Hz-60Hz.
- Display 4 digits LED.
- Product size (W×H×D) 80mm x 150mm x 230mm.
| SKU | UTP1306 |
|---|---|
| Brand | UNI-T |
