Specifications weights and dimensions:

• Depth: 1 mm.
• Height: 6 mm.
• Width: 13.9 mm.
• Net weight: 0.52 g.

Temperatures:

• Storage temperature: -25 °C...55 °C.

Material data:

• Material: Copper.
• Colour: grey.

System specifications:

• Version for cross-connection link.

Additional technical data:

• Not an explosion-tested version.
• Installation advice: Mount directly.
• Type of fixing when screwed in.

Cross-connector:

• 2 cross-connected terminals.
• Rated current, 2-pole: 57 A.
• Rated current, multi-pole: 32 A.
• Cross-connector type.

Dimensions:

• Pitch in mm (P): 7.9 mm.

General:

• Number of poles: 2.

Rating data:

• Rated current: 41 A.
