R-Net / F-Net communication card 1 Mbps Speed 64-nodes 750m max
Description:
- The RNet communication board establishes a rapid series communication link between the PLC of the LSIS and the SV-iS7 inverter, enabling the PLC sequence program to drive the inverter using 1 Mbps high-speed communication.
- Installing and modifying the system is made simpler when inverters are controlled and monitored via a PLC sequence program.
- By using two communication lines to connect many inverters, it is possible to save installation time by using straightforward wiring and simple replacement.
- Factory automation can be simplified by connecting additional PLC devices and systems, such as PCs, to facilitate communication.
Specifications:
- 1Mbps Communication speed.
- Manchester Bi-phase-L Frame synchronization.
- Max. 64 node connection points.
- Max. 750m transmission distance (segment each).
- Maximum protocol size: 256 bytes.
iS7 Series:
- With its improved V/F control, V/F PG slip compensation, and sensor-less vector control, the iS7 produces more potent performance.
- Focusing on an intuitive user interface and environmentally friendly features, the iS7 has a broad graphic LCD keypad with support for both user and macro groups, as well as an electro-thermal function for motor protection and input/output phase loss protection.
- A speed-precision-driven vector algorithm and a competitive and powerful low-speed torque control are features of iS7 technology.
- 100:1 speed control range.
- Very low torque control capability: actual torque of 150% at 0.1 Hz.
- Maximum torque control capacity inside the range of restoration.
| SKU | SV-IS7-RNet |
|---|---|
| Brand | LS Electric |
