RAPIEnet I/F Communication Module, Electric 2 ports
Description:
- It is a 10/100Base-TX-compatible industrial high-speed Ethernet-based communication module.
- Modbus TCP, User-defined communication, and LS dedicated communication are supported.
Specifications:
- Communication Ports: 2 Ethernet ports.
- Supported Protocols: RAPIEnet, EtherNet/IP, Modbus TCP/IP.
- Data Transfer Rate: Up to 1 Gbps.
- Network Topologies Supported: Ring, Star, and Line.
- Maximum Distance:
- Electrical: 100 meters.
- Fiber Optic: 2 km.
- Noise Reduction: Fiber optic network minimizes electromagnetic interference.
- Compatibility: Integrates with various automation products including PLCs, remote I/O, and drives.
- Engineering Tools: Compatible with XG5000 and DriveView 9 for easy setup and maintenance.
- Built-in Features: Supports hybrid network configurations (electric/fiber optic).
- Power Supply: 24V DC.
- Operating Temperature: -20°C to 60°C.
- Dimensions:
- Height: 90 mm.
- Width: 70 mm.
- Depth: 60 mm.
- Weight: 0.3 kg.
| Brand | LS Electric |
|---|
