Specifications:

• Operation Voltage: 10~30VDC / 24VAC
• Communication Baud Rate: 2400~921600bps
• Isolation: YES (5000VDC)
• Input Operating Frequency: 10HZ.
• Output Operating Frequency: Transistor: 10HZ.
• Operation Temperature: -20 to +75 °C
• Degree Of Protection: IP20
• Installation: 35 mm DIN rail or Flush mounting
• Dimension (W x H x D mm): 76.4*118.2*38.5 mm
• Analog Inputs: 8 (16-bit)
• Analog Input Type: 0/2~10V
• Analog Input / Output Accuracy: ±0.1% / ±1%
• Interface: RS-485 + USB
• Channel Independent Configuration: YES
• Sampling Rate: 10 sample/second (total)

Inputs:

• 4*Isolation DI
• Status low: < 1VDC
• Status high: > 5~30VDC
