Specifications:

• Function Voltage: 24 VAC / 10~30 VDC
  Two * Isolation DI inputs
• Low status: less than 1VDC
• High status: >5~30 VDC
• Two* (Transistor) outputs
• Constant Current: 1A at 10~35 VDC
• Baud Rate of Communication: 2400–921600 bps
• Yes, isolation (5000VDC)
• Operating frequency of input: 10 Hz.
• Transistor operating frequency for the output is 10 Hz.
• Warmth Range for Operation: -20 to +75 °C
• Protection Level: IP20
• Installing: flush mounting or 35 mm DIN rail
• Dimensions: 76.4 * 118.2 * 38.5 mm (W x H x D mm).
• Four analog (16-bit) inputs
• 2*0/2~10V‌2*PT-100/1000, (-200 ~ +600°C) is the type of analog input.
• Twelve-bit analog outputs: two
• Type of Analog Output: 0/2~10V
• Enter Data Impedance: RTD: 10MΩ / Current: 100 Ω.
• Accuracy of analog input/output: ±0.1% / ±1%
• Interface: USB Channel, RS-485, and WiFi Separate Setting up: AGREE
• Sample Rate: Ten samples per second in total
• 120 dB CMR at 50/60 Hz
