SFC 0/12 MC NE WS

ZAR 0.00 ZAR 0.00
Out of stock
SKU
1813130000

Pricing available on request

SFC 0/12 MC NE WS:

  • Halogen-free conductor and cable markings with a compact design are called SlimFix X.
  • The markers can be attached even after the conductor has been installed.
  • SlimFix is a recognized and certified marker type in traffic engineering.
  • The SF tool enables for simple installation, even with small markers.
  • substance devoid of halogens.
  • certified and authorized markers for use in traffic engineering, etc.
  • Cable ties are required for conductors having a cross section bigger than 16.0 mm².
  • Markers in the popular MultiCard format.

Dimensions and weights:

  • Depth: 7 mm.
  • Depth (inches): 0.276 inch.
  • Height: 12 mm.
  • Height (inches): 0.472 inch.
  • Width: 5.8 mm.
  • Width (inches): 0.228 inch.
  • Net weight: 0.483 g.

Temperatures:

  • Operating temperature range: -40...100 °C.

Environmental Product Compliance:

  • REACH SVHC: /.
  • RoHS Compliance Status: Compliant without exemption.

General data:

  • Colour: White.
  • compatible printer: PRINTJET CONNECT.
  • Halogen: No.
  • Material: Polyamide 66.
  • Material colour according to resistance code: 9.
  • Number of markers per combination: 1 MultiCard = Conductor and cable markers.
  • Number of markers per packaging unit:
    • Form of supply: MultiCard.
  • Operating temperature range: -40...100 °C.
  • Operating temperature range, max.: 100 °C.
  • Operating temperature range, min.: -40 °C.
  • Recommended industries: Transportation, Machinery.
  • Size of labelling field: 12 x 4.1 mm.
  • Type of printing: neutral.
  • UL 94 flammability rating: V-2.
  • Width: 5.8 mm.

Conductor and cable markers:

  • Conductor cross-section, max.: 1 mm².
  • Conductor cross-section, min.: 0.5 mm².
  • Conductor O.D.: 1.5 – 2.5 mm.
  • Conductor O.D., max.: 2.5 mm.
  • Conductor O.D., min.: 1.5 mm.
  • Cross-section for connected wire: 0.5 - 1 mm².
  • Halogen: No.
More Information
SKU 1813130000
Brand Weidmuller
