Siemens S7-1200 Ethernet/Telecontrol CP 1243-1 Security
Pricing available on request
Communications processor CP 1243-1 for connection of SIMATIC S7-1200:
- Supply voltage, current consumption, power loss.
- Type of voltage / of the supply voltage: DC
- Supply voltage / 1 / from backplane bus: 5 V
- Consumed current:
- From backplane bus / at DC / at 5 V / typical: 0.25 A
- Power loss [W]: 1.25 W
Transfer rate:
- At the 1st interface: 10 ...100 Mbit/s
Interfaces:
- Number of interfaces / according to Industrial Ethernet: 1
- Number of electrical connections at the 1st interface / according to Industrial Ethernet: 1
- For power supply: 0
- Type of electrical connection at the 1st interface / according to Industrial Ethernet: RJ45 port
Ambient temperature:
- For vertical installation / during operation: -20 ... +60 °C
- For horizontally arranged busbars / during operation: -20 ... +70 °C
- During storage: -40 ... +70 °C
- During transport: -40 ... +70 °C
- Relative humidity at 25 °C / without condensation / during operation / maximum: 95 %
- Protection class IP: IP20
Design, dimensions and weights:
- Module format: Compact module S7-1200 single width
- Width: 30 mm
- Height: 110 mm
- Depth: 75 mm
- Net weight: 0.122 kg
Fastening method:
- 35 mm top hat DIN rail mounting: Yes
| SKU | 6GK7243-1BX30-0XE0 |
|---|---|
| Brand | Siemens |
