Specifications:

• Electrical Characteristics:
• Supply Voltage: 24 V DC.
• Backplane Bus Current: 55 mA.
• Power Loss: 0.4 W.
• Destruction Limits:
• Voltage: ±35 V.
• Current: 40 mA.
• Analog Input:
• Channels: 1.
• Input Types:
• Voltage: ±10 V, ±5 V, ±2.5 V.
• Current: 0–20 mA.
• Input Resistance:
• Voltage: ≥9 MΩ.
• Current: ≥250 Ω.
• Resolution: 11-bit + sign.
• Measurement Principle: Integrating.
• Cycle Time: 156.25 µs (400 Hz suppression).
• Smoothing: Parameterizable (None, Low, Medium, High).
• Accuracy:
• ±0.3% @ 25 °C.
• ±0.6% up to 55 °C.
• Mechanical & Environmental:
• Dimensions (W x H x D): 38 × 62 × 21 mm.
• Mounting: Direct CPU attachment.
• Protection Rating: IP20.
• Operating Temp: –20 to +60 °C.
• Storage Temp: –40 to +70 °C.
• Humidity: Up to 95% (non-condensing).
• Weight: ~35 g.
• Compliance & Approvals:
• CE, UL, CSA, FM, RCM, KC.
• Marine: DNV, BV, RMRS, CCS, ABS, RINA.
• Hazardous Location: ATEX, IECEx.
• Diagnostic LEDs for input status and maintenance.
