Specifications:

• Electrical Characteristics:
• Backplane Bus Current: 15 mA (typical).
• Power Loss: 1.5 W.
• Transmitter Supply Current: Max 25 mA.
• Analog Output:
• Channels: 1.
• Output Ranges:
• Voltage: ±10 V.
• Current: 0–20 mA.
• Resolution:
• Voltage: 12-bit.
• Current: 11-bit.
• Load Impedance:
• Voltage: ≥1000 Ω.
• Current: ≤600 Ω.
• Conversion Principle: Differential.
• Cycle Time:
• Voltage: 300 µs (resistive), 750 µs (1 µF).
• Current: 600 µs (1 mH), 2 ms (10 mH).
• Cable Length: Up to 100 m (shielded, twisted pair).
• Accuracy & Diagnostics:
• Temperature Error:
• ±0.5% at 25 °C.
• ±1% up to 55 °C.
• Diagnostics:
• LED status indication.
• Alarms and fault detection supported.
• Mechanical & Environmental:
• Dimensions (W x H x D): 38 × 62 × 21 mm.
• Mounting: Direct CPU attachment.
• Protection Rating: IP20.
• Operating Temp: –20 to +60 °C (horizontal).
• Storage Temp: –40 to +70 °C.
• Humidity: Up to 95% (non-condensing).
• Weight: ~40 g.
• Compliance & Approvals:
• CE, UL, CSA, FM, RCM, KC.
• Marine: DNV, BV, RMRS, CCS, ABS, RINA.
• Hazardous Location: ATEX, IECEx.
• Diagnostic LED for output status.
