Siemens S7-1200 SIMATIC HMI KTP700 Basic
Pricing available on request
Description:
- The TP700 Comfort is a 7-inch widescreen touch panel from Siemens’ SIMATIC HMI Comfort series, designed for demanding applications in machine-level HMI.
- It features a TFT display with 800 × 480 resolution, supports 16 million colours, and offers multi-language, vector-based graphics for intuitive user interaction.
Specifications:
- Display Size: 7" TFT widescreen.
- Resolution: 800 × 480 pixels.
- Colour Depth: 16 million colours.
- Touch Technology: Analog resistive.
- Processor: ARM-based, high-performance.
- RAM / Flash: 128 MB / 512 MB.
- Interfaces: 2 × Ethernet (RJ45), 1 × USB host, 1 × USB device.
- Expansion: SD card slot (up to 32 GB).
- Power Supply: 24 V DC (19.2–28.8 V range).
- Power Consumption: ~12 W typical.
- Mounting: Panel flush mount.
- Protection Class: IP65 (front), IP20 (rear).
- Operating Temperature: 0 °C to +50 °C.
- Certifications: CE, UL, cULus, RCM, KC.
- Software Compatibility: WinCC Comfort or higher, TIA Portal.
| SKU | 6AV2123-2GA03-0AX0 |
|---|---|
| Brand | Siemens |
