Siemens S7-1200 Simulator (14 positions for CPU 1214C/1215C)
Pricing available on request
Description:
- This module is a digital output signal board for the S7-1200 CPU family, offering 16 digital outputs in a compact form factor.
- It connects directly to the CPU via the signal board interface, allowing output expansion without increasing the overall footprint—ideal for modular control systems.
Specifications:
- Module Type: Digital Output Signal Board.
- Number of Outputs: 16.
- Output Type: Transistor (source).
- Rated Output Voltage: 24 V DC.
- Max Output Current per Channel: 0.5 A.
- Total Current (per group): 3 A max.
- Isolation: Galvanic isolation between groups.
- Connection Type: 40-pin connector.
- Mounting: Directly on CPU via signal board slot.
- Dimensions (W × H × D): ~38 × 62 × 21 mm.
- Net Weight: ~60 g.
- Ambient Temperature (Operation): –20 °C to +60 °C.
- Ambient Temperature (Storage): –40 °C to +70 °C.
- Protection Class: IP20.
- Certifications: CE, cULus, KC.
| SKU | 6ES7274-1XH30-0XA0 |
|---|---|
| Brand | Siemens |
