Specifications:

• Electrical Characteristics:
• Supply Voltage Range: 20.4 V to 28.8 V DC.
• Backplane Bus Current: Max 125 mA.
• Power Loss: ~8 W.
• Load Voltage L+ Current: Max 170 mA.
• Digital Outputs:
• Channels: 4.
• Rated Output Voltage: 24 V DC.
• Rated Output Current: 2 A per channel.
• Permissible Range: 10 mA to 2.4 A.
• Residual Current (signal “0”): Max 0.5 mA (P-switch & M-switch).
• Switching Frequency:
• Resistive Load: 30 Hz.
• Lamp Load: 10 Hz.
• Short-Circuit Protection: Yes.
• Cable Length: Up to 200 m (shielded or unshielded).
• Safety & Compliance:
• Safety Protocol : PROFIsafe.
• Performance Level (ISO 13849-1): PL e, Category 4.
• SIL Rating (IEC 61508): SIL 3.
• PFDavg (Low Demand Mode): < 1.00 × 10⁻⁵.
• PFH (High Demand Mode): < 4.00 × 10⁻⁹.
• Certifications: CE, UL, FM, RCM, ATEX, IECEx.
• Marine Approvals: DNV, LRS, RMRS, CCS, KR.
• Mechanical & Environmental:
• Dimensions (W x H x D): 70 x 100 x 75 mm.
• Weight: ~270 g.
• Mounting: DIN rail.
• Protection Rating: IP20.
• Operating Temp: 0 to +55 °C.
• Storage Temp: –40 to +70 °C.
• Humidity: Up to 95% (non-condensing).
