Specifications:

• Electrical Characteristics:
• Supply Voltage: 24 V DC.
• Backplane Bus Current: 80 mA (typical).
• Power Loss: 1.5 W.
• Current Consumption: 45 mA (typical).
• Analog Outputs:
• Channels: 2.
• Output Types:
• Voltage: ±10 V (14-bit resolution).
• Current: 0–20 mA / 4–20 mA (13-bit resolution).
• Load Impedance:
• Voltage: ≥1 kΩ.
• Current: ≤600 Ω.
• Cable Length: Up to 100 m (shielded, twisted pair).
• Accuracy & Diagnostics:
• Temperature Error:
• ±0.3% at 25 °C.
• ±0.6% up to 55 °C.
• Basic Error Limit:
• Voltage: ±0.3%.
• Current: ±0.3%.
• Diagnostics:
• Wire break.
• Short-circuit.
• Supply voltage monitoring.
• Diagnostic alarms.
• LEDs for output status and maintenance.
• Mechanical & Environmental:
• Dimensions (W x H x D): 45 x 100 x 75 mm.
• Mounting: DIN rail.
• Protection Rating: IP20.
• Operating Temp: –20 to +60 °C.
• Storage Temp: –40 to +70 °C.
• Humidity: Up to 95% (non-condensing).
• Weight: ~180 g.
• Compliance & Approvals:
• CE, UL, CSA, FM, RCM, KC.
• Marine: DNV, LRS, BV, RMRS, RINA, CCS.
• Environmental Product Declaration (EPD).
• Global Warming Potential: 36.4 kg CO₂ eq.
