Specifications:

• Display Size: 12" TFT colour.
• Resolution: 1280 × 800 pixels.
• Touch Type: Analog-resistive.
• Function Keys: 10 programmable keys.
• Backlight Lifetime: ~20,000 hours.
• Processor: ARM-based.
• RAM / Flash: 128 MB each.
• User Memory: 10 MB.
• Interface: 1 × Ethernet (RJ45), 1 × USB host.
• Protocols Supported: PROFINET, Modbus TCP/IP, EtherNet/IP.
• Power Supply: 24 V DC (19.2–28.8 V range).
• Power Consumption: ~6 W.
• Dimensions (W×H×D): 330 × 243 × 39.4 mm.
• Mounting Cutout: 314 × 227 mm.
• Weight: ~1.9 kg.
• Environmental Ratings:
• Operating Temp: 0 to +50 °C.
• Storage Temp: –20 to +60 °C.
• Humidity: Up to 90% (non-condensing).
• Protection Class: IP65 (front), IP20 (rear).
• Vibration/Shock: IEC 60068-2 compliant.
• Certifications & Approvals:
• CE, UL, CSA, RCM, KC.
• Marine: ABS, BV, DNV, LRS, RINA, NK.
• EMC: EN 61000-6-2 / EN 61000-6-4.
• Environmental Product Declaration (EPD).
• Global Warming Potential: ~85 kg CO₂ eq.
