connection method:

• Connection I/O signals:
• Connection method: Push-in terminal.
• Number of lines per connection: 1; or max. 8x 2 conductors to 1.5 mm² (in total) in a shared end sleeve and max. 32x 0.75 mm² single core.
• Conductor cross-section in mm²:
• Connectable cable cross-sections for massive cables, min.: 0.25 mm².
• Connectable cable cross-sections for massive cables, min.: 1.5 mm²; max. 32x 0.75 mm², 8x 1.5 mm².
• Connectable cable cross-sections for flexible cables without end sleeve, min.: 0.25 mm².
• Connectable cable cross-sections for flexible cables without end sleeve, max.: 1.5 mm²; max. 32x 0.75 mm², 8x 1.5 mm².
• Connectable cable cross-sections for flexible cables with end sleeve, min.: 0.25 mm².
• Connectable cable cross-sections for flexible cables with end sleeve, max.: 1.5 mm²; max. 32x 0.75 mm², 8x 1.5 mm².
• Conductor cross-section acc. to AWG:
• Connectable cable cross-sections for massive cables, min.: 24.
• Connectable cable cross-sections for massive cables, min.: 16; max. 32x AWG 19, 8x AWG 16.
• Connectable cable cross-sections for flexible cables without end sleeve, min.: 24.
• Connectable cable cross-sections for flexible cables without end sleeve, max.: 16; max. 32x AWG 19, 8x AWG 16.
• Connectable cable cross-sections for flexible cables with end sleeve, min.: 24.
• Connectable cable cross-sections for flexible cables with end sleeve, max.: 16; max. 32x AWG 19, 8x AWG 16.
• Wire end processing:
• Stripped length of cables, min.: 8 mm.
• Stripped length of cables, max.: 11 mm.
• End sleeve acc. to DIN 46228 without plastic sleeve: Form A, 10 mm long.
• End sleeve acc. to DIN 46228 with plastic sleeve: Form E, 8 mm and 10 mm long.
• Mounting:
• Tool: Screwdriver, conical design, 3 mm to 3.5 mm.

Dimensions:

• Width: 19.8 mm.
• Height: 130.5 mm.
• Depth: 43 mm.

Weights:

• Weight, approx.: 123 g.
