Specifications:

• suitability for use: For connection to IE FC TP cables 2x2, suitable for fast assembly with the
  FastConnect system.

transfer rate:

• transfer rate / for Industrial Ethernet: 10 Mbit/s, 100 Mbit/s.

interfaces:

• number of electrical connections.
• for Industrial Ethernet FC TP cables: 4.
• for network components or terminal equipment: 1.
• type of electrical connection.
• for Industrial Ethernet FC TP cables: integrated cut-and-clamp contacts for 4-wire TP FC installation cable AWG22.
• for network components or terminal equipment: RJ45 connector.
• type of electrical connection / FastConnect: Yes.

mechanical data:

• material / of the enclosure: metal.
• number of reuses: 10.
• locking mechanism design: other.

design, dimensions and weights:

• type of cable outlet: 180° cable outlet.
• width: 13.7 mm.
• height: 16 mm.
• depth: 55 mm.
• net weight: 35 g.
• connectable cable cross-section: 6.5 ... 6.5 mm.
• connectable conductor cross-section: 0.33 mm².

ambient conditions:

• ambient temperature.
• during operation: -40 ... +85 °C.
• during storage: -40 ... +85 °C.
• during transport: -40 ... +85 °C.
• relative humidity.
• at 25 °C / without condensation / during operation / Maximum: 95 %.
• protection class IP: IP20.

product features, product functions, product components / general:

• product feature.
• PoE capability: Yes.
• PoE+capability: Yes.
• silicon-free: Yes.
• product component.
• strain relief: Yes.

standards, specifications, approvals:

• certificate of suitability.
• RoHS conformity: Yes.
• UL approval: Yes.
• cULus approval: Yes.
• railway application in accordance with EN 50155: No.
• standard for structured cabling: Cat5.

standards, specifications, approvals / Environmental Product Declaration:

• Environmental Product Declaration: Yes.
• Global Warming Potential [CO2 eq].
• total: 0.277 kg.
• during manufacturing: 0.263 kg.
• during operation: 0.0086 kg.
• after end of life: 0.0062 kg.
