Input:

• type of the power supply network: 1-phase AC.
• supply voltage at AC: Automatic range selection.
• supply voltage: 120 V/230 V.
• input voltage 1 at AC: 85 ... 132 V.
• input voltage 2 at AC: 170 ... 264 V.
• wide range input: No.
• overvoltage overload capability: 2.3 × Vin rated, 1.3 ms.
• buffering time for rated value of the output current in the event of power failure minimum: 20 ms.
• operating condition of the mains buffering: at Vin = 93/187 V.
• line frequency: 50/60 Hz.
• line frequency: 45 ... 65 Hz.
• input current:
• at rated input voltage 120 V: 3.7 A.
• at rated input voltage 230 V: 1.7 A.
• current limitation of inrush current at 25 °C maximum: 62 A.
• duration of inrush current limiting at 25 °C:
• maximum: 3 ms.
• I2t value maximum: 12 A²·s.
• fuse protection type: T 6.3,15 A/250 V (not accessible).
• fuse protection type in the feeder: Recommended miniature circuit breaker: 16 A characteristic B or 10 A characteristic C.

Output:

• voltage curve at output: Controlled, isolated DC voltage.
• output voltage at DC rated value: 24 V.
• output voltage:
• at output 1 at DC rated value: 24 V.
• output voltage adjustable: No.
• relative overall tolerance of the voltage: 1 %.
• relative control precision of the output voltage.
• on slow fluctuation of input voltage: 0.1 %.
• on slow fluctuation of ohm loading: 0.1 %.
• residual ripple:
• maximum: 50 mV.
• voltage peak:
• maximum: 150 mV.
• display version for normal operation: LED green for 24 V OK; LED red for error; LED yellow for stand-by.
• behavior of the output voltage when switching on: No overshoot of Vout (soft start).
• response delay maximum: 1.5 s.
• voltage increase time of the output voltage:
• typical: 10 ms.
• output current:
• rated value: 8 A.
• rated range: 0 ... 8 A.
• supplied active power typical: 192 W.
• short-term overload current:
• on short-circuiting during the start-up typical: 35 A.
• at short-circuit during operation typical: 35 A.
• duration of overloading capability for excess current:
• on short-circuiting during the start-up: 70 ms.
• at short-circuit during operation: 70 ms.
• bridging of equipment: Yes.
• number of parallel-switched equipment resources for increasing the power: 2.

efficiency:

• efficiency in percent: 90 %.
• power loss [W]:
• at rated output voltage for rated value of the output current typical: 21 W.
