Siemens S7-1500 SIPLUS SM 531 Analog input modules SIPLUS S7-1500 AI 8XU/I HS
Pricing available on request
Description:
- This technology module offers 8 digital channels, each configurable as input or output, with integrated timer functionality.
- It is optimized for event-driven control, pulse generation, and time-based logic, making it ideal for packaging, material handling, and machine sequencing applications.
Specifications:
- Channels: 8 (configurable as DI or DQ).
- Signal Type: 24 VDC (IEC 61131 Type 1).
- Input Delay: 0.05–20 ms (parameterizable).
- Output Current: Max 0.5 A per channel.
- Total Output Current: Max 3 A per group.
- Timer Functions: Pulse, delay, edge detection, frequency.
- Timer Resolution: 1 µs.
- Timer Range: Up to 4.29 billion µs (≈71 minutes).
- Switching Frequency: Up to 1 kHz (resistive); 10 Hz (inductive).
- Diagnostics: Channel diagnostics, wire break, short.
- Power Loss: ~3.5 W.
- Backplane Bus Consumption: ~1.1 W.
- Dimensions (W×H×D): 35 × 147 × 129 mm.
- Weight: ~300 g.
- Environmental & Compliance:
- Operating Temp: –30 °C to +60 °C.
- Humidity: 100% RH with condensation/frost.
- Altitude: Up to 5000 m.
- Isolation Test Voltage: 707 V DC.
- Protection Class: IP20.
- Approvals: CE, UL, ATEX, IECEx, DNV, FM, CCC, RCM.
- Global Warming Potential: ~37.6 kg CO₂ eq (lifecycle).
| SKU | 6AG1531-7NF10-7AB0 |
|---|---|
| Brand | Siemens |
