General information:

• Product type designation: DQ 8x24VDC/2A HF.
• HW functional status: From FS03.
• Firmware version: V2.2.0.
• FW update possible: Yes.
• Product function:
• I&M data: Yes; I&M0 to I&M3.
• Isochronous mode: No.
• Prioritized startup: Yes.
• Engineering with:
• STEP 7 TIA Portal configurable/integrated from version: V13 SP1 / -.
• STEP 7 configurable/integrated from version: V5.5 SP3 / -.
• PROFIBUS from GSD version/GSD revision: V1.0 / V5.1.
• PROFINET from GSD version/GSD revision: V2.3 / -.
• Operating mode:
• DQ: Yes.
• DQ: with energy-saving function Yes; with an application.
• PWM: Yes.
• Cam control (switching at comparison values): No.
• Oversampling: No.
• MSO: Yes.
• Integrated operating cycle counter: Yes.

Supply voltage:

• Rated value (DC): 24 V.
• permissible range, lower limit (DC): 19.2 V.
• permissible range, upper limit (DC): 28.8 V.
• Reverse polarity protection: Yes; through internal protection with 10 A per group.

Input current:

• Current consumption, max.: 40 mA; 20 mA per group, no output is activated.

output voltage / header:

• Rated value (DC): 24 V.

Power:

• Power available from the backplane bus: 0.9 W.

Power loss:

• Power loss, typ.: 5.6 W; 6.8 W for PWM operation.

Digital outputs:

• Type of digital output: Transistor.
• Number of digital outputs: 8.
• Current sourcing: Yes.
• Digital outputs, parameterizable: Yes.
• Short-circuit protection: Yes.
• Response threshold, typ.: 3 A.
• Limitation of inductive shutdown voltage to: -17 V.
• Controlling a digital input: Yes.
• Digital output functions, parameterizable:
• Freely usable digital output: Yes.
• PWM output: Yes; FS02 and FW V2.1.0 or higher.
• Number, max.: 2.
• Cycle duration, parameterizable: Yes; 2 ... 100 ms continuous.
• ON period, min.: 0 %.
• ON period, max.: 100 %.
• Resolution of the duty cycle: 0.1 %.
• Minimum pulse duration: 300 µs.
• Switching capacity of the outputs:
• on lamp load, max.: 10 W.
• Load resistance range:
• lower limit: 12 Ω.
• upper limit: 4 kΩ.
• Output voltage:
• for signal "1", min.: L+ (-0.8 V).
• Output current:
• for signal "1" rated value: 2 A.
• for signal "1" permissible range, max.: 2.4 A; note derating specification for PWM operation.
• for signal "0" residual current, max.: 0.5 mA.
• Output delay with resistive load:
• "0" to "1", typ.: 80 µs.
• "0" to "1", max.: 100 µs.
• "1" to "0", typ.: 300 µs.
• "1" to "0", max.: 500 µs.
• Parallel switching of two outputs:
• for logic links: Yes.
• for uprating: No.
• for redundant control of a load: Yes.
• Switching frequency:
• with resistive load, max.: 100 Hz; With PWM operation: 500 Hz.
• with inductive load, max.: 0.5 Hz; According to IEC 60947-5-1, DC-13; max. 500 Hz with PWM operation only with external circuit; see additional description in the manual.
• on lamp load, max.: 10 Hz.
• Total current of the outputs:
• Current per channel, max.: 2 A; see additional description in the manual.
• Current per group, max.: 8 A; see additional description in the manual.
• Current per module, max.: 16 A; see additional description in the manual.
• Cable length:
• shielded, max.: 1 000 m.
• unshielded, max.: 600 m.

Interrupts/diagnostics/status information:

• Diagnostics function: Yes.
• Substitute values connectable: Yes.
• Alarms:
• Diagnostic alarm: Yes.
• Maintenance interrupt: Yes.
• Diagnoses:
• Monitoring the supply voltage: Yes.
• Wire-break: No.
• Short-circuit: Yes.
• Group error: Yes.
• Diagnostics indication LED:
• RUN LED: Yes; green LED.
• ERROR LED: Yes; red LED.
• MAINT LED: Yes; Yellow LED.
• Monitoring of the supply voltage (PWR-LED): Yes; green LED.
• Channel status display: Yes; green LED.
• for channel diagnostics: Yes; red LED.
• for module diagnostics: Yes; red LED.

Potential separation:

• Potential separation channels:
• between the channels: No.
• between the channels, in groups of: 4.
• between the channels and backplane bus: Yes.

Isolation:

• Isolation tested with: 707 V DC (type test).

Standards, approvals, certificates:

• Suitable for safety functions: No.
• Suitable for safety-related tripping of standard modules: Yes; From FS03.
• Highest safety class achievable for safety-related tripping of standard modules:
• Performance level according to ISO 13849-1: PL d.
• Category according to ISO 13849-1: Cat. 3.
• SIL acc. to IEC 62061: SIL 2.

product functions / security / header:

• signed firmware update: No.
• data integrity: No.

Ambient conditions:

• Ambient temperature during operation:
• horizontal installation, min.: -30 °C; From FS06.
• horizontal installation, max.: 60 °C.
• vertical installation, min.: -30 °C; From FS06.
• vertical installation, max.: 40 °C.
• Altitude during operation relating to sea level:
• Installation altitude above sea level, max.: 5 000 m; Restrictions for installation altitudes > 2 000 m, see manual.

Dimensions:

• Width: 35 mm.
• Height: 147 mm.
• Depth: 129 mm.

Weights:

• Weight, approx.: 240 g.
