Specifications:

• Input Channels: 8 (4 for RTD, all configurable).
• Signal Types Supported: Voltage, Current, RTD, Thermocouple.
• Resolution: 16-bit.
• Accuracy: ±0.3% (typical); ±0.1% at 25 °C.
• Temperature Compensation: Internal, external RTD, or fixed value.
• Encoder Supply: 24 VDC, short-circuit protected.
• Max Encoder Output: 20 mA (47 mA peak <10 s).
• Input Voltage Ranges: ±10 V, ±1 V, ±250 mV, ±500 mV, ±80 mV.
• Input Current Ranges: 0–20 mA, ±20 mA, 4–20 mA.
• RTD Types Supported: Pt100, Pt200, Pt500, Pt1000, Ni100, Ni1000.
• TC Types Supported: B, E, J, K, N, R, S, T.
• Integration Time Options: 2.5 / 16.67 / 20 / 100 ms.
• Conversion Time: 9–107 ms depending on mode.
• Cable Length: 800 m (U/I), 200 m (RTD), 50 m (TC).
• Power Loss: ~2.7 W.
• Dimensions (W×H×D): 35 × 147 × 129 mm.
• Weight: ~310 g.
• Environmental & Compliance:
• Operating Temp: –25 °C to +60 °C.
• Humidity: 100% RH with condensation/frost.
• Altitude: Up to 5000 m.
• Conformal Coating: Siemens EcoTech certified.
• Approvals: CE, UL, ATEX, IECEx, DNV, FM, CCC, RCM.
• AMS 2750 & CQI-9 Compliance: Yes (thermal processing standards).
• Global Warming Potential: 38.6 kg CO₂ eq (lifecycle).
