Siemens S7-1500 Terminal module TPRi, (110 V AC) screw-type terminals with LEDs
Pricing available on request
Description:
- This is a TPRO connection module with 8 transistor outputs, tailored for interfacing SIMATIC S7-300/1500 PLCs with DC-driven field actuators.
- It supports electronic switching of loads up to 30 V DC / 0.5 A per channel and includes status LEDs for each output plus power indication.
- The screw terminals offer secure, torque-controlled connections—ideal for vibration-prone environments.
Specifications:
- Module Type: TPRO (Transistor Output Module).
- Terminal Type: Screw-type terminals with LED indication.
- Number of Channels: 8 (transistor outputs).
- Output Type: Electronic (transistor).
- Switching Capacity: 30 V DC / 0.5 A per channel.
- Operating Voltage: 24 V DC (nominal), 28.8 V DC (max).
- Max Current per Pin: 0.5 A.
- Total Current: 4 A.
- LED Indicators: Yellow (I/O status), Green (power OK).
- Terminal Cross-Section Range: 0.5–2.5 mm² (with ferrules).
- Mounting: DIN rail (35 mm or 15 mm), any position.
- Dimensions (W × H × D): 100 × 76 × 60 mm.
- Ambient Temperature (Operation): 0 °C to +60 °C.
- Ambient Temperature (Storage): –40 °C to +70 °C.
- Combustibility Class (UL 94): V1.
- Pollution Degree / Overvoltage Category: 2 / II.
- Approvals: cULus, CE, RCM certified.
- Net Weight: ~230 g.
- Environmental Product Declaration: Yes (GWP: 234.2 kg CO₂ eq total).
| SKU | 6ES7924-0BG20-0BA0 |
|---|---|
| Brand | Siemens |
