Signal Analyzers, UTS3000A-AMA
UTS3000A Series, Signal Analysers:
- Frequency range: 9 kHz to 8.4 GHz.
- DANL: -165 dBm (typical).
- Phase noise is typically less than -100 dBc/Hz at 10 kHz offset.
- Scan up to 40,001 points.
- Minimum resolution bandwidth (RBW): 1 Hz.
- Support sophisticated one-key measurements (optional).
- EMI Analysis Function (Optional).
- Analog demodulation analysis support is available (optional).
- Support Digital Demodulation Analysis (optional).
- Support real-time spectrum analysis.
- Support I/Q analysis (optional).
- Support Vector Network Analysis.
- 10.1-inch high-definition capacitive touchscreen display.
Specifications:
- UTS3000A Series, Signal Analysers.
- Analog Demodulation Analysis.
- Demodulation Frequency Range: 2 MHz to 8.4 GHz.
- Carrier Power Accuracy: ± 2 db.
- Input Power: -30 dBm to +20 dBm (Auto attenuation).
- Carrier Power Resolution: 0.01 dBm.
- AM Measurement:
- Modulation Frequency: 20 Hz to 100 kHz.
- Modulation Depth: 5% to 95%.
- Accuracy: ±4% (Nominal).
- FM Measurement:
- Modulation Frequency: 20 Hz to 100 kHz.
- Frequency Offset: 1 kHz to 400 kHz.
- Accuracy: ±4% (Nominal).
- PM Measurement:
- Modulation Frequency: 20 Hz to 100 kHz.
- Phase Offset: 0.2 to 6.28 rad.
- Accuracy: ±4% (Nominal).
| SKU | UTS3000A-AMA |
|---|---|
| Brand | UNI-T |
