Signal Analyzers, UTS3000A-AMK
UTS3000A Series, Signal Analysers:
- Frequency range: 9 kHz to 8.4 GHz.
- DANL: -165 dBm (typical).
- Phase noise is typically less than -100 dBc/Hz at 10 kHz offset.
- Scan up to 40,001 points.
- Minimum resolution bandwidth (RBW): 1 Hz.
- Support sophisticated one-key measurements (optional).
- EMI Analysis Function (Optional).
- Analog demodulation analysis support is available (optional).
- Support Digital Demodulation Analysis (optional).
- Support real-time spectrum analysis.
- Support I/Q analysis (optional).
- Support Vector Network Analysis.
- 10.1-inch high-definition capacitive touchscreen display.
Specifications:
- UTS3000A Series, Signal Analysers.
- Power Measurement:
- Channel Power: Channel Power, Power Spectral Density.
- Adjacent Channel Power Ratio (ACPR): Main Channel Power, Lower Power/Power Ratio, Higher Power/Power Ratio.
- Occupied Bandwidth (OBW): Occupied Bandwidth, Total Power, Transmit Frequency Error.
- Time Domain Power: Zero Span Time Integrated Power.
- Carrier Noise Ratio (CNR): Carrier Power, Noise Power, Carrier Noise Ratio.
- Non-Linear Measurement:
- Third-Order Intermodulation (TOI): Based on dual-tone peak search.
- Harmonic Analysis: Maximum Harmonic 10.
- Spectrum Monitor: - Visualization: Waterfall Plot.
| SKU | UTS3000A-AMK |
|---|---|
| Brand | UNI-T |
