Signal Analyzers, UTS3000A-B40
UTS3000A Series, Signal Analysers:
- Frequency range: 9 kHz to 8.4 GHz.
- DANL: -165 dBm (typical).
- Phase noise is typically less than -100 dBc/Hz at 10 kHz offset.
- Scan up to 40,001 points.
- Minimum resolution bandwidth (RBW): 1 Hz.
- Support sophisticated one-key measurements (optional).
- EMI Analysis Function (Optional).
- Analog demodulation analysis support is available (optional).
- Support Digital Demodulation Analysis (optional).
- Support real-time spectrum analysis.
- Support I/Q analysis (optional).
- Support Vector Network Analysis.
- 10.1-inch high-definition capacitive touchscreen display.
Specifications:
- UTS3000A Series, Signal Analysers.
- Expands Standard RTSA from 10 MHz to 40 MHz
- Real-Time Spectrum Analysis Bandwidth: Expands from 10 MHz to 40 MHz with this option.
- Signal Duration for 100% POI at Full-Scale Accuracy: - Maximum Span (Kaiser window): 6.68 μs.
- Detection Modes: Peak, Negative Peak, Sample, Average.
- Trace Display Options: Normal, Density, Spectrogram, PVT, PVT Spectrum, PVT Spectrogram, Power gram, Power gram Spectrogram.
- Resolution Bandwidth (RBW): 6 RBW options for each window, except the rectangle window.
- Frequency Span: - Min: 133.3324 kHz, Max: 4.2716 MHz (for 40 MHz bandwidth) - 25 MHz Span: Min: 66.6662 kHz, Max: 2.1358 MHz - 10 MHz Span: Min: 33.3331 kHz, Max: 1.0679 MHz
- Trigger Options: Free run, External trigger, Power (time), Frequency Mask Template (FMT).
- Dynamic Range: 200 dB Bitmap colour.
- History Depth: 10,000.
| SKU | UTS3000A-B40 |
|---|---|
| Brand | UNI-T |
