Signal Analyzers, UTS3000A-EMI
UTS3000A Series, Signal Analysers:
- Frequency range: 9 kHz to 8.4 GHz.
- DANL: -165 dBm (typical).
- Phase noise is typically less than -100 dBc/Hz at 10 kHz offset.
- Scan up to 40,001 points.
- Minimum resolution bandwidth (RBW): 1 Hz.
- Support sophisticated one-key measurements (optional).
- EMI Analysis Function (Optional).
- Analog demodulation analysis support is available (optional).
- Support Digital Demodulation Analysis (optional).
- Support real-time spectrum analysis.
- Support I/Q analysis (optional).
- Support Vector Network Analysis.
- 10.1-inch high-definition capacitive touchscreen display.
Specifications:
- UTS3000A Series, Signal Analysers.
- Resolution Bandwidth: 200 Hz, 9 kHz, 120 kHz, 1 MHz
- EMI Detector Types: Peak, Negative Peak, Quasi Peak, EMI Average, Average.
- EMI Standards: CISPR, AS-NZS, Bell Core, DEF-STAN, DO-160, EN, FCC, GB9254, MIL-461, VCCI, Custom.
- Scan Sequences: Scan, Search, Scan-Search-Meas, Scan-Search, Search-Meas, Measure.
- Signal Table Settings: Customizable for specific test requirements.
- Meter Control: Precise control for EMI testing.
| SKU | UTS3000A-EMI |
|---|---|
| Brand | UNI-T |
