Signal Analyzers, UTS3000A-FDD-LTE
UTS3000A Series, Signal Analysers:
- Frequency range: 9 kHz to 8.4 GHz.
- DANL: -165 dBm (typical).
- Phase noise is typically less than -100 dBc/Hz at 10 kHz offset.
- Scan up to 40,001 points.
- Minimum resolution bandwidth (RBW): 1 Hz.
- Support sophisticated one-key measurements (optional).
- EMI Analysis Function (Optional).
- Analog demodulation analysis support is available (optional).
- Support Digital Demodulation Analysis (optional).
- Support real-time spectrum analysis.
- Support I/Q analysis (optional).
- Support Vector Network Analysis.
- 10.1-inch high-definition capacitive touchscreen display.
Specifications:
- UTS3000A Series, Signal Analysers.
- FDD-LTE (Frequency Division Duplex Long-Term Evolution) demodulation analysis is used to evaluate and troubleshoot the performance of FDD-LTE wireless communication systems.
- This type of analysis helps engineers assess signal quality by decoding and examining key parameters such as modulation schemes, error vector magnitude (EVM), channel power, and signal-to-noise ratio (SNR).
- It is crucial for identifying issues related to signal integrity, interference, and protocol compliance, allowing engineers to optimize base stations, network performance, and user equipment in mobile networks.
- With the UNI-T UTS3000A Signal Analyzer UTS3000A-FDD-LTE option enabled, you can affordably perform simple and complex analysis of your LTE communication signals.
| SKU | UTS3000A-FDD-LTE |
|---|---|
| Brand | UNI-T |
