Signal Analyzers, UTS3000A-I/Q
UTS3000A Series, Signal Analysers:
- Frequency range: 9 kHz to 8.4 GHz.
- DANL: -165 dBm (typical).
- Phase noise is typically less than -100 dBc/Hz at 10 kHz offset.
- Scan up to 40,001 points.
- Minimum resolution bandwidth (RBW): 1 Hz.
- Support sophisticated one-key measurements (optional).
- EMI Analysis Function (Optional).
- Analog demodulation analysis support is available (optional).
- Support Digital Demodulation Analysis (optional).
- Support real-time spectrum analysis.
- Support I/Q analysis (optional).
- Support Vector Network Analysis.
- 10.1-inch high-definition capacitive touchscreen display.
Specifications:
- UTS3000A Series, Signal Analysers.
- I/Q Analysis.
- Frequency Range: 50 Hz to 8.4 GHz.
- Modulation Types: - BPSK, QPSK, 8BPSK, DQPSK, D8PSK, π/4-DQPSK, π/8-D8PSK, OQPSK - QAM: 16, 32, 64, 128, 256.
- Symbol Length: 10 to 4096 symbols.
- Symbol Rate: 1 ksps to analysis bandwidth /symbol point.
- Filter Types: Raised Cosine, Gaussian, EDGE, CDMA, Rectangular.
- Display: IQ Diagrams, Eye Diagrams, Constellation Diagrams.
- Error Statistics: EVM, Magnitude Error, Phase Error, Gain Imbalance.
| SKU | UTS3000A-I-Q |
|---|---|
| Brand | UNI-T |
