Signal Analyzers, UTS3000A-TDD-LTE
UTS3000A Series, Signal Analysers:
- Frequency range: 9 kHz to 8.4 GHz.
- DANL: -165 dBm (typical).
- Phase noise is typically less than -100 dBc/Hz at 10 kHz offset.
- Scan up to 40,001 points.
- Minimum resolution bandwidth (RBW): 1 Hz.
- Support sophisticated one-key measurements (optional).
- EMI Analysis Function (Optional).
- Analog demodulation analysis support is available (optional).
- Support Digital Demodulation Analysis (optional).
- Support real-time spectrum analysis.
- Support I/Q analysis (optional).
- Support Vector Network Analysis.
- 10.1-inch high-definition capacitive touchscreen display.
Specifications:
- UTS3000A Series, Signal Analysers.
- TDD-LTE (Time Division Duplex Long-Term Evolution) demodulation analysis is used to evaluate and troubleshoot the performance of TDD-LTE wireless communication systems, where uplink and downlink transmissions share the same frequency but occur at different times.
- This analysis focuses on assessing the quality and integrity of the modulated signal, including parameters such as modulation schemes (QPSK, 16QAM, etc.), signal-to-noise ratio (SNR), error vector magnitude (EVM), and timing synchronization.
- By conducting TDD-LTE demodulation analysis, engineers can identify signal impairments, detect timing and synchronization issues, optimize resource allocation, and ensure the overall performance of the network.
- This is especially important in environments with heavy data traffic or interference, helping maintain efficient and stable communication in mobile networks.
- With the UNI-T UTS3000A Signal Analyzer UTS3000A-TDD-LTE option enabled, you can affordably perform simple and complex analysis of your LTE signal.
| SKU | UTS3000A-TDD-LTE |
|---|---|
| Brand | UNI-T |
