Signal Analyzers, UTS3000A-VSA
UTS3000A Series, Signal Analysers:
- Frequency range: 9 kHz to 8.4 GHz.
- DANL: -165 dBm (typical).
- Phase noise is typically less than -100 dBc/Hz at 10 kHz offset.
- Scan up to 40,001 points.
- Minimum resolution bandwidth (RBW): 1 Hz.
- Support sophisticated one-key measurements (optional).
- EMI Analysis Function (Optional).
- Analog demodulation analysis support is available (optional).
- Support Digital Demodulation Analysis (optional).
- Support real-time spectrum analysis.
- Support I/Q analysis (optional).
- Support Vector Network Analysis.
- 10.1-inch high-definition capacitive touchscreen display.
Specifications:
- UTS3000A Series, Signal Analysers.
- Vector Signal Analysis.
- Modulation Types: - ASK: 2ASK, 4ASK, 8ASK, and 16ASK - FSK: 2FSK, 4FSK, 8FSK, and 16FSK - MSK: Type 1, Type 2 - PSK: BPSK, QPSK, OQPSK, 8PSK, DQPSK, 8BPSK, π/4-DQPSK, π/8-D8PSK, OQPSK - QAM: 16, 32, 64, 128, 256.
- Symbol Length: 10 to 4096 symbols.
- Filter Types: No Filter, Raised Root Cosine (RRC), Gaussian, EDGE, CDMA, Rectangular.
- Measurement Statistics: Symbol Error, Error Vector Magnitude (EVM), Phase Error, IQ Offset, Carrier Offset, and SNR.
- Display Options: IQ Diagram, Constellation Diagram, Eye Diagrams, Phase Diagrams.
- IQ Measurement: Time Domain, Frequency Domain.
| SKU | UTS3000A-VSA |
|---|---|
| Brand | UNI-T |
