Specifications:

• Electrical Characteristics:
• Rated Output Voltage: 5 V DC.
• Output Type: MOSFET, solid-state (sinking/sourcing).
• Switching Capacity:
• Max 0.1 A per channel (resistive load).
• Output Voltage Levels:
• Signal “0”: Max 0.2 V.
• Signal “1”: Min L+ – 0.7 V, Max 6 V.
• Output Current:
• Rated: 0.1 A.
• Max permissible: 0.1 A.
• Short-Circuit Protection: Not available.
• Power Loss: 0.5 W.
• Backplane Bus Current: 35 mA.
• Digital Outputs:
• Channels: 4.
• Group Configuration: Single group of 4.
• Max Frequency: 200 kHz.
• Cable Length:
• Shielded: 50 m.
• Mechanical & Environmental:
• Dimensions (W x H x D): 38 × 62 × 21 mm.
• Mounting: Direct CPU attachment.
• Protection Rating: IP20.
• Operating Temp: –20 to +60 °C.
• Storage Temp: –40 to +70 °C.
• Humidity: Up to 95% (non-condensing).
• Weight: ~35 g.
• Compliance & Approvals:
• CE, UL, CSA, FM, RCM, KC.
• Marine: DNV, LRS, BV, RMRS, CCS.
• EMC & RoHS Compliant.
• Environmental Confirmations: China RoHS, UKCA, IECEx, ATEX.
