Specifications:

• Channels: 8 isolated analog inputs.
• Resolution: 13 bits.
• Conversion Time: ~66 ms per channel.
• Input Voltage Range: ±10 V, ±5 V, ±1 V, 0–10 V, 1–5 V.
• Input Current Range: 0–20 mA, 4–20 mA.
• RTD Support: Pt100, Ni100, Ni1000, LG-Ni1000.
• Resistance Range: 0–600 Ω and 0–6 kΩ.
• Input Protection: 30 V (voltage), 40 mA (current).
• Isolation: Yes (channel-to-backplane).
• Diagnostics: No onboard diagnostics or alarms.
• Power Loss: ~0.4 W.
• Bus Current Draw: 90 mA @ 5 V DC.
• Dimensions (W×H×D): 40 × 125 × 117 mm.
• Connector: 40-pin front connector.
• Weight: ~250 g.
• Measurement Accuracy:
• Voltage:
• Typical Error @ 25 °C: ±0.3–0.4%.
• Max Error (Full Temp Range): ±0.5–0.6%
• Current:
• Typical Error @ 25 °C: ±0.3%.
• Max Error (Full Temp Range): ±0.5%.
• Resistance:
• Typical Error @ 25 °C: ±0.3%.
• Max Error (Full Temp Range): ±0.5%.
• RTD (e.g. Pt100):
• Typical Error @ 25 °C: ±0.8–1.2 K.
• Max Error (Full Temp Range): ±1–1.2 K.
