SKMU M40 - K GR
Description:
- The product line is completed by plugs, pressure compensation components, adaptors, and matching accessories like locknuts, sealing rings, flat washers, and earthing rings, in addition to cable glands for a variety of applications.
- If there isn't a threaded hole accessible, use it to secure cable glands and accessories.
- Featuring a circumferential collar to shield the substrate from harm while being installed.
Specifications:
- Version: SKMU PA (plastic locknut), Locknut.
- Quantity: 50.
- Height: 7 mm.
- Operating temperature: -40 °C...100 °C.
- AF size: 50 mm.
- Cable glands: M 40.
- External thread: M 40.
- No Halogen.
- Internal thread: M 40.
- Length of thread: 7 mm.
- Material: Polyamide 6 (PA6 - GF30).
- O.D.: 57.75 mm.
- Pitch of thread: 1.5 mm.
- No Silicone.
- Thickness: 7 mm.
- UL 94 flammability rating: HB.
| Brand | Weidmuller |
|---|
