SKMU PG7-K GR

ZAR 7.64
Out of stock
SKU
1697440000

SKMU PG7-K GR:

  • SKMU PA (plastic locknut), Locknut, PG 7, 5 mm, Polyamide 6 (PA6 - GF30).
  • In addition to cable glands for a variety of applications, the product line includes plugs, pressure compensation components, adaptors, and associated accessories such as locknuts, sealing rings, flat washers, and earthing rings.

Specifications dimensions and weights:

  • Height: 5 mm.
  • Height (inches): 0.197 inch.
  • Net weight: 1.1 g.

Temperatures:

  • Operating temperature: -40 °C - 100 °C.

Environmental Product Compliance:

  • REACH SVHC: /.

General information:

  • AF size 1: 19 mm.
  • Cable glands: PG 7.
  • External thread: PG 7.
  • Halogen: No.
  • Internal thread: PG 7.
  • Length of thread: 5 mm.
  • Material: Polyamide 6 (PA6 - GF30).
  • O.D.: 21.95 mm.
  • Operating temperature range, max.: 100 °C.
  • Operating temperature range, min.: -40 °C.
  • Pitch of thread: 1.27 mm.
  • Silicone: No.
  • Thickness: 5mm.
  • UL 94 flammability rating: HB.
More Information
Brand Weidmuller
