Spectrum/Signal Analyzers, UTS1000-AMA
UTS3000T+ Series, Spectrum/Signal Analysers:
- Frequency measurement range:9 kHz to 1.5GHz, 3.2 GHz, 3.6 GHz, 8.4 GHz.
- Display average noise level can be as low as -161 dBm (typical value).
- Phase noise <-98 dBc/Hz (Off set 10 kHz, typical value).
- Full amplitude accuracy <0.7 db.
- Minimum resolution bandwidth (RBW) 1 Hz.
- Advanced function one key measurement (optional).
- EMI Pre-compliance analysis function (optional).
- Support analog demodulation analysis (optional).
- Support tracking source output function.
- 10.1-inch 1280 × 800 HD capacitive touch screen.
Specifications:
- UTS3000T+ Series, Spectrum/Signal Analysers.
- UNI-T UTS1000-AMA Analog Demodulation Analysis Option.
- Demodulation:
- Frequency Range: (Spectrum Analyzer Model dependent): 2 MHz to 1.5 GHz, 2 MHz to 3.2 GHz.
- Carrier Power Precision: ± 2 db.
- Input Power: -30 dB to +20 dBm (Automatic attenuation).
- Carrier Power Display Resolution: 0.01 dBm.
- AM Measurement:
- Modulation Rate: 20 Hz to 100 kHz.
- Precision: 1 Hz (Nominal) for Modulation Rate < 1 kHz, < 0.1% Modulation Rate (Nominal) for Modulation Rate ≥ 1 kHz.
- Depth: 5% to 95%.
- Depth Precision: ± 4% (Nominal).
- FM Measurement:
- Modulation Rate: 20 Hz to 100 kHz.
- Precision: 1 Hz (Nominal) for Modulation Rate < 1 kHz, < 0.1% Modulation Rate (Nominal) for Modulation Rate ≥ 1 kHz.
- Frequency Offset: 1 kHz to 400 kHz.
- Frequency Offset Precision: ± 4% (Nominal).
| SKU | UTS1000-AMA |
|---|---|
| Brand | UNI-T |
