Spectrum/Signal Analyzers, UTS1000-AMK
UTS3000T+ Series, Spectrum/Signal Analysers:
- The frequency measurement ranges from 9 kHz to 1.5 GHz, 3.2 GHz, 3.6 GHz, and 8.4 GHz.
- The display average noise level can be as low as -161 dBm (typical value).
- Phase noise is less than -98 dBc/Hz (offset 10 kHz is common).
- Full amplitude accuracy is <0.7 db.
- Minimum resolution bandwidth (RBW): 1 Hz.
- Advanced function: one key measurement (optional).
- The EMI pre-compliance analysis function is optional.
- Analog demodulation analysis support is optional.
- Support the tracking of the source output function.
- 10.1-inch HD capacitive touch screen with a resolution of 1280 x 800.
Specifications:
- UTS3000T+ Series, Spectrum/Signal Analysers.
- Unlock the UNI-T Advanced Measurement Kit for calculating the following:
- Power Measurement:
- Channel power: Channel power, Power spectral density.
- ACP (Adjacent Channel Power): Main CH Power, left channel power, Right channel power.
- Occupied bandwidth: Occupied Bandwidth, Transmit Frequency Error.
- Time domain power: Zero Span Integrated Power.
- CNR (Carrier Noise Ratio): C/N, Noise Power.
- Non-Linear Measurement:
- TOI, Third-order intercept: Measure the third-order products from two tones.
- Harmonic measurement: Max Harmonic number 10.
- Spectrum Monitor Measurement: - Spectrogram.
| SKU | UTS1000-AMK |
|---|---|
| Brand | UNI-T |
