Spectrum/Signal Analyzers, UTS1015T 1.5GHz Advanced-Series
UTS1000B Series, Spectrum/Signal Analysers:
- Frequency range: 9 kHz–3.2 GHz.
- Resolution bandwidth: 1 Hz to 1 MHz
- Tracking frequency range: 100 kHz to 3.2 GHz.
- DANL: -161 dBm.
- Phase noise: <-98dBc/Hz (1 GHz typical).
- The number of scanning points displayed is 10001.
- Analysis functions include EMI analysis, sophisticated measurement, and analog and digital demodulation analysis.
- Display: 10.1" TFT LCD (1280x800) touch screen.
- Interface: HDMI, USB host, USB device, LAN, and 3.5mm audio.
Specifications:
- UTS1000B Series, Spectrum/Signal Analysers.
- Frequency Range 9kHz–1.5GHz.
- RBW 1Hz–1MHz
- DANL -161dBm/Hz.
- Traces 4.
- Scan Points 10,001.
- Tracking Generator Included.
- Display Size (in) 10.1in.
- Touchscreen Yes.
- Warranty 3 years.
- Product Dimensions (L x W x H) 15 in x 9 in x 5 in.
- Product Weight 10 lb.
- Certifications CE/cETLus/UKCA.
| SKU | UTS1015T |
|---|---|
| Brand | UNI-T |
