System module MS2210-0022-1214
The MS2200-2022-1214 bus coupler is the link between the EtherCAT protocol and the MX modules. In addition to coupling the data communication, the integrated B17 hybrid connector is also used to feed the control voltage of 24 V DC and 48 V AC with up to 10 A into the MX-System.
Product category: system modules
Category/version: EtherCAT power infeed
Output voltage data connector: 24/48 V DC
Output voltage forwarding: 24/48 V DC
Output current data connector: 10 A
Output current forwarding: 10 A
Connection method: B17
External supply voltage: 24/48 V DC
External feed current: 10 A max.
Distance between stations: max. 100 m (100BASE-TX)
Baseplate interface: data connector
Diagnostics: yes
Hot swap: no
TwinCAT version: TwinCAT 3
Weight: 400 g
Approvals/markings: CE, (UL in preparation)
Dimensions (W x H x D): 30 mm × 110 mm × 72 mm
Number of rows: 1
Number of slots: 1
Material: zinc and aluminum die-cast
Cooling: convection
Operating/storage temperature: 0…+50 °C/-25…+85 °C
Protect. rating/installation pos.: IP65/67/variable
| SKU | MS2210-0022-1214 |
|---|
