System module MS2610-1002-1334
The MS2610-1002-1334 EtherCAT power infeed module serves as the link between the EtherCAT protocol and the MX-System modules.
Product category: system modules
Category/version: EtherCAT power infeed
Output voltage data connector: 24 V DC
Output voltage forwarding: 230 V AC
Output current data connector: 7 A
Output current forwarding: 7 A
Connection method: B17
External supply voltage: 230 V AC
External feed current: 10 A max.
Distance between stations: max. 100 m (100BASE-TX)
Power supply unit: 24 V
Baseplate interface: data connector
Diagnostics: yes
Hot swap: no
TwinCAT version: TwinCAT 3
Weight: 1100 g
Approvals/markings: CE, (UL in preparation)
Dimensions (W x H x D): 110 mm x 110 mm x 72 mm
Number of rows: 1
Number of slots: 3
Material: zinc and aluminum die-cast
Cooling: convection
Operating/storage temperature: 0…+50 °C/-25…+85 °C
Protect. rating/installation pos.: IP65/67/variable
| SKU | MS2610-1002-1334 |
|---|
