System module MS4306-1903-1111
The module MS4306-1900-1111 is an EtherCAT power output for control voltages incl. EtherCAT communication. Power and data communication run combined via the EtherCAT-P single cable solution via M8 connector. Up to 6 A (2 x 3 A) on 24 V can be distributed to supply a remote control unit. The voltage can be switched off safely.
Product category: system modules
Category/version: EtherCAT power output
Output voltage forwarding: 24 V DC
Output current forwarding: 6 A (2 x 3 A)
Connection method: M8
Supply voltage from backplane: 24 V DC
Baseplate interface: data connector
Diagnostics: yes
Hot swap: no
TwinCAT version: TwinCAT 3
Approvals/markings: CE, (UL in preparation)
Dimensions (W x H x D): 30 mm × 110 mm × 72 mm
Number of rows: 1
Number of slots: 1
Material: zinc and aluminum die-cast
Cooling: convection
Operating/storage temperature: 0…+50 °C/-25…+85 °C
Protect. rating/installation pos.: IP65/67/variable
| SKU | MS4306-1903-1111 |
|---|
