System module MS4520-1051-2245
The module MS4520-1051-2245 is an EtherCAT power output for power voltages incl. EtherCAT communication. Via the integrated B23 hybrid connector, in addition to the coupling of the data communication via EtherCAT-P and 24 V in the data core for the control voltage, the power supply of 400 V AC and 600 V DC with up to 20 A is also implemented in the MX system.
Product category: system modules
Category/version: EtherCAT power output
Output voltage forwarding: 400 V AC/24 + 600 V DC
Output current forwarding: 20 A/6A (2 x 3 A)
Connection method: B23
Supply voltage from backplane: 400 V AC/24 + 600 V DC
Fuse: replaceable
Baseplate interface: data and power connector
Diagnostics: yes
Hot swap: no
TwinCAT version: TwinCAT 3
Approvals/markings: CE, (UL in preparation)
Dimensions (W x H x D): 70 mm × 240 mm × 112 mm
Number of rows: 2
Number of slots: 2
Material: zinc and aluminum die-cast
Cooling: convection
Operating/storage temperature: 0…+50 °C/-25…+85 °C
Protect. rating/installation pos.: IP65/67/variable
| SKU | MS4520-1051-2245 |
|---|
