System module MS6018-1100-2240
The MS4118-2400-2240 is a three-phase, 24 V DC power supply with an output current of 18 A and an output power of 432 W. On the input side, the device features a wide-range input, active power factor correction (PFC) and inrush current limitation. The output behavior and the output power are individually adjustable.
Product category: system modules
Category/version: power supply
Output voltage data connector: 24 V DC
Output current data connector: 18 A
Supply voltage from backplane: 400…480 V AC
Power supply unit: 24 V
Performance: PFC
Baseplate interface: data and power connector
Diagnostics: yes
Hot swap: no
TwinCAT version: TwinCAT 3
Approvals/markings: CE, (UL in preparation)
Dimensions (W x H x D): 70 mm × 240 mm × 112 mm
Number of rows: 2
Number of slots: 2
Material: zinc and aluminum die-cast
Cooling: convection
Operating/storage temperature: 0…+50 °C/-25…+85 °C
Protect. rating/installation pos.: IP65/67/variable
| SKU | MS6018-1100-2240 |
|---|
