System module PC UPS MS8132-0120-1212
The MS8132-0120-1212 UPS module monitors the 24 V control voltage and detects an undervoltage. In the event of undervoltage, the M12 connectors on the front are powered from the battery. This means that an IPC module as well as an operating panel can be simultaneously supplied with 24 V. Port X1 has the Beckhoff OCT-UPS interface and is able to communicate with a corresponding device via this interface.
Product category: system modules
Category/version: UPS
Connection method: M12
Supply voltage from backplane: 24 V DC
Channels: 2
Baseplate interface: data connector
Diagnostics: yes
Hot swap: no
TwinCAT version: TwinCAT 3
Weight: 400 g
Approvals/markings: CE, (UL in preparation)
Dimensions (W x H x D): 70 mm × 110 mm × 72 mm
Number of rows: 1
Number of slots: 2
Material: zinc die-cast
Cooling: convection
Operating/storage temperature: 0…+50 °C/-25…+85 °C
Protect. rating/installation pos.: IP65/67/variable
| SKU | MS8132-0120-1212 |
|---|
