system modules MS1410-1001-1334
The MS1416-1001-1334 module is a power supply module with black main switch that can be operated at a 230 V AC socket. A power supply unit with an output current of 7 A DC is already integrated to supply the 24 V DC control voltage.
Product category: system modules
Category/version: power infeed
Output voltage data connector: 24 V DC
Output current data connector: 7 A
Connection method: B17
External supply voltage: 230 V AC
External feed current: 10 A max.
Color: black
Power supply unit: 24 V
Fuse: without
Baseplate interface: data connector
Diagnostics: yes
Hot swap: no
TwinCAT version: TwinCAT 3
Approvals/markings: CE, (UL in preparation)
Dimensions (W x H x D): 110 mm x 110 mm x 72 mm
Number of rows: 1
Number of slots: 3
Material: zinc and aluminum die-cast
Cooling: convection
Operating/storage temperature: 0…+50 °C/-25…+85 °C
Protect. rating/installation pos.: IP65/67/variable
| SKU | MS1410-1001-1334 |
|---|
