system modules MS2520-8051-2245
The EtherCAT power supply module MS2520-8051-2245 is the link between the EtherCAT protocol and the MX-System modules. In addition to the coupling of the data communication via EtherCAT-P and 24 V in the data core for the control voltage, the power supply of 400 V AC and 600 V DC with up to 20 A into the MX-System is realized via the integrated B23 hybrid connector. In addition, a DC link capacity is installed.
Product category: system modules
Category/version: EtherCAT power infeed
Output voltage data connector: 24 V DC
Output voltage power connector: 400 V AC/600 V DC
Output current data connector: 6 A (2 x 3 A)
Output current power connector: 20 A
Connection method: B23
External supply voltage: 400 V…480 V AC/600 V DC
External feed current: 25 A max.
Capacity: for intermediate circuit
Distance between stations: max. 100 m (100BASE-TX)
Baseplate interface: data and power connector
Diagnostics: yes
Hot swap: no
TwinCAT version: TwinCAT 3
Approvals/markings: CE, (UL in preparation)
Dimensions (W x H x D): 70 mm × 240 mm × 112 mm
Number of rows: 2
Number of slots: 2
Material: zinc and aluminum die-cast
Cooling: convection
Operating/storage temperature: 0…+50 °C/-25…+85 °C
Protect. rating/installation pos.: IP65/67/variable
| SKU | MS2520-8051-2245 |
|---|
