system modules MS2620-1051-2245

Product category: system modules Category/version: EtherCAT power infeed Output voltage data connector: 24 V DC Output voltage power connector: 400 V AC/600 V DC Output current data connector: 18 A Output current power connector: 20 A Connection method: B23 External supply voltage: 400 V…480 V AC/600 V DC External feed current: 25 A max. Distance between stations: max. 100 m (100BASE-TX) Power supply unit: 24 V Baseplate interface: data and power connector Diagnostics: yes Hot swap: no TwinCAT version: TwinCAT 3 Weight: 2300 g Approvals/markings: CE, (UL in preparation) Dimensions (W x H x D): 70 mm × 240 mm × 112 mm Number of rows: 2 Number of slots: 2 Material: zinc and aluminum die-cast Cooling: convection Operating/storage temperature: 0…+50 °C/-25…+85 °C Protect. rating/installation pos.: IP65/67/variable
