TBF 37/30/18 trsp

ZAR 0.00
Out of stock
SKU
0500800000

Pricing available on request

Key Features:

  • High ingress protection is ensured by the IP67 High Protection Class.
  • Impact Resistance: Has a maximum impact resistance of 7 Joules.
  • Corrosion resistance makes it appropriate for severe settings.
  • Mounting Options: Mounting feet or fixing holes can be used for direct wall mounting.
  • Lid Fastening: Fastened with captive crosshead screws made of stainless steel.
  • Sealing: For improved impermeability, use a silicone or chloroprene-based moulded gasket.
  • Fire Rating: Depending on the configuration, up to an E60 fire rating.
  • Certifications: ATEX, IECEX, UL, and other certifications for usage in hazardous environments.

Specifications:

  • Model: TBF 37/30/18 TRSP.
  • Dimensions: 372 mm (Height) x 302 mm (Width) x 175 mm (Depth).
  • Material: Glass-fibre reinforced polyester.
  • Colour: Light Grey (RAL 7035), Transparent.
  • Operating Temperature: -50°C to 130°C.
  • Mounting Dimensions:
  • Width: 302 mm.
  • Height: 372 mm.
  • Net Weight: Approximately 2,465 grams.
  • Cable Glands: Various sizes available (M16, M20, etc.).
More Information
Brand Weidmuller
