TwinCAT 3 Bode Plot Base TE1320
The TwinCAT 3 Bode Plot Base is a standard tool in the TwinCAT Engineering for the optimization of drives. Due to the excitation on the drive axis to be examined, frequency response and phase are output graphically in the Bode Plot and as a result indicate possible optimizations. Several plots can be simulated and at the same time displayed. The tool is automatically installed as a standard tool with the TwinCAT 3 Engineering.
The TwinCAT 3 Filter Designer is a graphic engineering tool for determining the coefficients of digital filters. In Microsoft Visual Studio® it integrates seamlessly with the existing TwinCAT 3 engineering environment.
Required license: TC1000
Operating system: Windows 7, Windows 10
| SKU | TE1320 |
|---|
