TwinCAT 3 CNC E, platform level 91 (Other 5…8 Cores)
TwinCAT 3 CNC in the export version (E version) offers the option to implement an interpolation with up to four simultaneously interpolating axes. The number of axes and/or the number of channels can be adapted to the requirements of the application via the option packages.
Required License: TC1260
Operating system: Windows 7, Windows 10, TwinCAT/BSD
CPU architecture: x86, x64
• max. 8 path axes/controlled spindles, max. 64 axes/controlled spindles (optional), max. 12 channels
• max. 4 interpolationg path axes
• supports electric servo axes, stepper motor drives
• subroutine and jump technology, programmable loops, zero point shifts, tool corrections, M and H functions, mathematical functions, programming of parameters/variables, user macros, spindle and auxiliary functions, tool functions
• geometry functions linear, circular and helical interpolation at the main levels and freely definable levels, max. 64 path axes per channel, look-ahead function
• axis functions, coupling and gantry axis function, override, axis error and sag compensation, measuring functions
• programming in DIN 66025 with high-level language extension
• access via function blocks from TwinCAT PLC according to IEC 61131-3
• operation with automatic mode, manual mode (jog/inch), single block mode, referencing, block advance, handwheel mode (movement/overlay)
• convenient debugging with online monitoring of all states
| SKU | TF5210-0v91 |
|---|
