USB to RS232 Serial Converter
Pricing available on request
Description:
- The durable USB-Serial adapter, model number US232R, is intended for usage in a variety of environments.
- The collection of communication devices that make up the USB-RS232 adaptor cables.
- The US232R model offers a straightforward way to convert older serial devices with RS232 interfaces to USB ports.
- A compact internal electrical circuit board that makes use of the FTDI FT232R is housed inside a durable plastic enclosure that can tolerate a wide variety of industrial temperatures in each US232R adapter.
- TXD/RXD LEDs and RS232 level shifters are additional integrated electronics that show data flow via the adapter visually.
- A regular USB-A device connector is integrated into the cable so that it can be connected to a hub port or upstream host.
- Modem handshake signals and other RS232-level signals are accessible through an industry-standard DE-9P connector.
- 1 MBaud is the maximum data rate at the RS232 level.
- To make the US232R adapter cable appear as a Virtual COM Port (VCP), USB device drivers are required.
- This makes it possible for current serial communications applications, like HyperTerminal, to communicate with legacy RS232 peripheral devices by sending data over the US232R.
Specifications:
- Cable length: 100cm
- Operating temperature of -20°C to +80°C
- Special high gloss white finish enclosure design.
- Side-lit blue RXD and TXD traffic indicators.
- Quality 4-layer PCB design.
Features:
- Adds one RS-232 serial port by connecting to USB.
- Enhanced RS232 transceiver gives serial port speed of up to 1MBaud.
- Gold plated USB and DB9 connectors for enhanced connection reliability.
- Integral 10cm (US232R-10) or 100cm (US232R-100) or 500cm (US232R-500)
- USB cable with molded strain relief.
- Easy plug and play installation and RS-232 device connection.
- Works with USB 1.1 and 2.0 Host and Hub ports.
- Industry Standard FTDI chip set and device drivers for maximum compatibility.
- Microsoft Windows WHQL-certified, Mac OS X, Linux and Windows CE device drivers.
- Installs as a standard Windows COM port.
- COM port number can be changed to any available COM port number, including COM1 to COM4, to support HyperTerminal, or any other serial communications software application running in Windows.
- FIFO: 128 bytes transmit buffer; 256 bytes receive buffer.
- RS-232 data signals: TxD, RxD, RTS, CTS, DSR, DTR, DCD, RI, GND Powered by USB port.
- No external power adapter required.
- Serial Communication Parameters
- Parity: None, Even, Odd
- Data bits: 7, 8
- Flow control: RTS/CTS, DSR/DTR, X-ON/X-OFF, None
- Stop bits 1,2.
- The US232R is a lead-free device that complies with the following environmental directives: RoHS, WEEE, REACH, PFOS and DecaBDE.
| SKU | US232R-100 |
|---|---|
| Brand | LS Electric |
